7/16 Female - 4.3/10 Male

Materials & Plating

Shell/Body - Brass, ALLOY3

Conductor - Phosphor Bronze,  Silver Plated

Insulator - PTFE

Electrical Characteristics

Impedance - 50 ohm

Frequency Range Max. - DC - 2.1 GHz

Dielectric Withstanding Voltage - 2500V(RMS)

Contact Resistance - Centre  ≤ 1mΩ, Outer ≤ 1.5mΩ

Insulation Resistance - ≥ 5000mΩ

VSWR - ≤ 1.1

IL - ≤ 0.1dB

PIM - 165dBc

Mechanical Characteristics

Mating - 4.3/10:M20X1-6H 7/16:M29x1.5-6g

Durability - ≥ 500 cycles

Environmental Characteristics

Temperature Range: -55°C to +155°C
