7/16 Male to 4.3/10 Female Adaptor

Materials and Plating

Body: Brass, Tri Alloy

Insulator: PTFE

Center Conductor: Phosphor Bronze, Gold Plated

Other: Brass, Tri Alloy

Electrical Specification

Impedance: 50 Ohm

Frequency Range:  DC-6Ghz

VSWR: ≤1.10

PIM: ≤-160dBm

Insertion Loss: ≤0.05*√f

Dielectric Withstanding Voltage: ≥2500V RMS,50Hz,at sea level

Dielectric Resistance: ≥5000MΩ

Mechanical Specification

Mating cycles: ≥100 cycle

Environmental Specification

Temperature Range -40℃～+85℃

Rosh-compliance Full ROHS compliance

Salt-fog test: 96h
