4.3/10 Male - 7/16 Male Adaptor

Materials & Plating

Body - Brass Tri-Alloy

Insulator - PTFE

Centre Conductor – Brass, Silver Plated

Other – Brass Tri-Alloy

Electrical

Characteristic Impedance - 50 ohm

Frequency Range - DC-6GHz

VSWR - ≤1.10

PIM ( @2-tonex20w) - ≤-160dBc

Insertion Loss - ≤0.05*√f

Dielectric Withstanding Voltage - ≥2500V RMS,50Hz, at sea level

Dielectric Resistance -  ≥5000MΩ

Mechanical

Durability Mating Cycles - ≥100 cycles

Environmental

Temperature Range: -40℃～+85℃

Rosh-compliance - Full ROHS compliance

Salt-fog test - 96h
