50W RF Termination Load (DC-6GHz, N-Male)

(Code: YL-50W-6-NM)
 Add to Enquiry List
50W RF Termination Load (DC-6GHz, N-Male)


Features
• Wide Frequency Band DC-6GHz

• 2G/3G/4G/LTE Coverage

• Low VSWR

• Widely used for In-building Solutions


 Technical & Mechanical Specification
 Model No.  YL-50W-6-NM
 Freq(MHz)  DC-6GHz
 VSWR  ≤1.25
 Power(W)  50 (average)
 Impedance  50 ohm
 Connector  N-male
 Colour  Black
 Temp(deg)  -30~+65
 Weight(kg)  0.45
