Adaptor UHF Male to N Male

Materials & Plating

Shell/Body - Brass, Nickel Plated

Conductor - Brass, Gold Plated

Insulator - PTFE

Electrical Characteristics

Impedance - 50 ohm

Frequency Range Max. - DC - 300MHz

Dielectric Withstanding Voltage - 750V(RMS)

Contact Resistance - Centre ≤ 5mΩ, Outer ≤ 5mΩ

Insulation Resistance - ≥ 5000mΩ

Mechanical Characteristics

Mating - 5/8-24UNEF-2B,

Durability - ≥ 500 cycles

Environmental Characteristics

Temperature Range: - 40°C to +85°C
