N Type Attenuator 15W, DC-3GHz N-Male to N-Female

(Code: MA-15-3G-NM/F)
 Add to Enquiry List
N Type Attenuator 15W, DC-3GHz N-Male to N-Female
Product Features
Wide Frequency Band DC-3GHz
Low Attenuation Accuracy
Low VSWR
Widely used in IBS &DAS
Indoor Application
Widely used for In-building Solutions

Technical & Mechanical Specifications
Power 15W
Freq (MHz) DC- 3GHz
VSWR ≤1.20
Power (W) 5 (average)
Attenuator (dB) 1, 3, 6, 10, 15, 20, 30
Accuracy (dB) ±0.5 (1/3/6): ±0.8 (10): ±1.0 (15/20/30)
Impedance 50 ohm
Connector N (M)-N (F)
Colour Black
Weight (kg) 0.25

Product Code Attenuation Accuracy
MA-3G-15-NM/F-01 1 ±0.5
MA-3G-15-NM/F-03    3 ±0.5
MA-3G-15-NM/F-06
 6 ±0.5
MA-3G-15-NM/F-10
 10 ±0.8
MA-3G-15-NM/F-15
 15 ±1.0
MA-3G-15-NM/F-20
 20 ±1.0
MA-3G-15-NM/F-30
 30 ±1.0
