Pliers 6A (Outer Crimp Tool)

(Code: 901-0001-007)
Add to Enquiry List
Pliers 6A (Outer Crimp Tool)




PCC-5310 is a tool frame for interchangeable crimp dies forcoaxial connectors, PCC-5310 die sets. The user can cover several connectors injust one tool frame.

  • High strength, through hardened alloy steel construction
  • Full cycle crimp mechanism to ensure consistent, reliable crimp
  • Ratchet release mechanism to clear miscrimps and obstructions
  • Precision eccentric adjustment for consistent performance and ability to calibrate
  • Each tool has a unique serial number for traceability
  • The part number is a reference to the frame without dies.

Technical Data

Length: 200 mm/7.87"

Width: 26 mm/1.02"

Height: 164 mm/6.46"

Weight: 525 gr/1.16 lb

Description: Tool frame for PCC-5310 die sets, coaxial connectors

Life span, cycles: 50,000
