SMB 75 ohm Right-Angled Plug (Solder) BT3002

Materials & Plating

Shell/Body - Brass, Gold Plated

Contact Socket - Brass, Gold Plated

Insulator - PTFE

Crimp Sleeve - Brass, Gold Plated



Electrical Characteristics

Impedance - 75 ohm

Frequency Range Max. - 0.2GHz

Dielectric Withstanding Voltage - 1000V (RMS)

Contact Resistance - Centre ≤ 6.0mΩ, Outer ≤ 1.0mΩ

Insulation Resistance - ≥ 1000mΩ



Mechanical Characteristics

Mating - snap-on coupling

Durability - ≥ 500 cycles



Environmental Characteristics

Temperature Range: - 55°C to +155°C



Assembly

Pin: Solder

Outer: 4.52 mm hex
