UHF Crimp Plug RG214 (Solder Pin)

(Code: 255-1024S-070)
Add to Enquiry List
UHF Crimp Plug RG214 (Solder Pin)

Materials & Plating

Shell/Body - Brass, Nickel Plated

Conductor - Brass, Silver Plated

Insulator - PTFE


Electrical Characteristics

Impedance - 50 ohm

Frequency Range Max. - DC - 300 MHz

Dielectric Withstanding Voltage - 2000V(RMS)

Contact Resistance - Centre ≤ 5mΩ, Outer ≤ 5mΩ

Insulation Resistance - ≥ 5000mΩ


Mechanical Characteristics

Mating - 5/8-24UNEF-2B

Durability - ≥ 500 cycles


Environmental Characteristics

Temperature Range: - 55C to +155C


Assembly

Pin: Solder

Outer: 10.9 mm hex
